A sheet with momentum.

The markup.

<dialog-panel> owns the modal layer, the native <dialog> is the surface that slides, and <bottom-sheet> turns pointer gestures into movement. The header draws the handle and is always draggable; the content flexes and scrolls on its own.

<dialog-panel id="sheet-panel">
  <dialog aria-labelledby="sheet-title">
    <bottom-sheet>
      <bottom-sheet-header>
        <h2 id="sheet-title">A useful title</h2>
        <button data-action-hide-dialog aria-label="Close">&times;</button>
      </bottom-sheet-header>
      <bottom-sheet-content>…</bottom-sheet-content>
    </bottom-sheet>
  </dialog>
</dialog-panel>

// the trigger is passed in so focus returns to it on close
sheet.show(trigger)

Scrolling hands off to dragging.

A downward drag on a list could mean scroll it, or move the panel. The sheet re-asks on every move rather than deciding once — scroll to the top, keep pulling, and the panel takes the gesture without a jump.

// re-asked on every move until it succeeds
if (moveY > 0) return content.scrollTop === 0;  // hand off at the top

// upward: below the tallest snap, growing beats scrolling
return snaps.length > 0 && activeSnap < snaps.at(-1);

// on the move that wins, remember where it started
drag.claimOffset = deltaY;
const travel = deltaY - drag.claimOffset;

Snap points.

Give the sheet snap-points="40,70,100" and each number becomes a resting height as a percentage of the viewport. A flick steps exactly one snap; anything slower lands on the nearest. Dragging below the shortest snap dismisses the sheet.

<bottom-sheet snap-points="40,70,100">…</bottom-sheet>

// the current snap reflects back, on commit only
sheet.snap          // 70
sheet.snapPoints    // [40, 70, 90]
sheet.snapTo(90);

sheet.addEventListener('snapChange', (e) => {
  console.log(e.detail); // { from: 70, to: 90 }
});

A map-style sheet.

The shape every maps app converges on: opens at a 25dvh peek, a search field in the fixed header, a results list below. Dragging up grows the sheet first — scrolling takes over at the tallest snap.

<bottom-sheet snap-points="25,55,92" snap="25">
  <bottom-sheet-header>…</bottom-sheet-header>   /* search field  */
  <bottom-sheet-content>…</bottom-sheet-content> /* results       */
</bottom-sheet>

// snap= sets the opening height; it reflects after that

A pinned footer.

Add <bottom-sheet-footer> and only the content between the fixed header and footer scrolls. The footer takes over the safe-area padding so its background runs under the home indicator — and it's a drag surface too.

<bottom-sheet>
  <bottom-sheet-header>…</bottom-sheet-header>   /* fixed  · drag surface */
  <bottom-sheet-content>…</bottom-sheet-content> /* flex: 1 · scrolls     */
  <bottom-sheet-footer>
    <button>Checkout</button>
  </bottom-sheet-footer>  /* fixed · owns the safe area */
</bottom-sheet>

/* bottom-sheet.css */
bottom-sheet-footer {
  padding: var(--bs-footer-padding, var(--bs-content-padding));
  padding-bottom: calc(var(--bs-footer-padding, var(--bs-content-padding)) + env(safe-area-inset-bottom, 0px));
}

A floating, inset sheet.

Add the inset attribute and the sheet detaches from the screen edges — all four corners rounded, a gap on three sides. It's pure CSS: :has(bottom-sheet[inset]) does the whole thing and no JavaScript runs.

<bottom-sheet inset>…</bottom-sheet>

dialog-panel:has(bottom-sheet[inset]) > dialog {
  left:  var(--bs-panel-inset-x);
  right: var(--bs-panel-inset-x);
  width: auto;
  border-radius: var(--bs-panel-border-radius);
  margin-bottom: calc(var(--bs-panel-inset-bottom) + env(safe-area-inset-bottom, 0px));
}

/* or it peeks by exactly the inset when hidden */
transform: translate3d(0, calc(100% + var(--bs-panel-inset-bottom) + env(safe-area-inset-bottom, 0px)), 0);

Inset + snap points.

The combination most likely to break, so it gets its own sheet. Two snaps, no middle ground — it peeks at 40 or takes the screen at 97. The tall snap stays under 100 so a detached sheet's top corners don't round off screen.

<bottom-sheet inset snap-points="40,97">…</bottom-sheet>

A maximum display width.

Set max-display-width="768" and the sheet only opens below 768px — and closes itself the moment the viewport widens past the limit. Narrow this window, open it, then widen the window and watch it leave.

<bottom-sheet max-display-width="768">…</bottom-sheet>

// or from script — Infinity removes the limit
sheet.maxDisplayWidth = 768;
sheet.maxDisplayWidth = Infinity;

Theming with custom properties.

The sliders write --bs-* custom properties onto the <dialog-panel> — that's the entire theming API. The switches toggle attributes on the sheet itself. Set the dials first: an open modal makes everything behind it inert.

// what every control on this page actually does
panel.style.setProperty('--bs-panel-border-radius', '25px');

/* or, far more likely, in your own stylesheet */
#my-panel {
  --bs-panel-background: #171012;
  --bs-handle-color: #9a6a5a;
}

Lifecycle events.

The parent panel fires beforeShow, shown, beforeHide, and hidden; the first and third are cancelable. Each carries detail.state, mirrored as a state attribute that drives the CSS. Open the sheet and close it to watch the sequence fill in.

No events yet.

const panel = document.querySelector('#sheet-panel');

for (const name of ['beforeShow', 'shown', 'beforeHide', 'hidden']) {
  panel.addEventListener(name, (event) => {
    console.log(name, event.detail.state);
  });
}

// cancelable — this sheet refuses to open
panel.addEventListener('beforeShow', (event) => event.preventDefault());

The full reference.

Four elements, one attribute, fourteen style tokens, two methods, and the panel's four lifecycle events. Everything else is ordinary HTML you write yourself.

import '@magic-spells/dialog-panel';
import '@magic-spells/bottom-sheet';

import '@magic-spells/dialog-panel/css';
import '@magic-spells/bottom-sheet/css';

const sheet = document.querySelector('bottom-sheet');
sheet.show(trigger);
sheet.hide();

Elements

Attributes

CSS Custom Properties

Methods & Properties

Events

The first four bubble, are composed, and are dispatched by the parent panel. Each detail object carries state, triggerElement, and result. snapChange comes from the <bottom-sheet> itself and carries { from, to } in dvh percent.

Accessibility

Modal semantics, focus trapping, focus return, Escape handling, and body scroll lock are delegated to the native <dialog> via showModal(), driven by the parent panel — the sheet adds no ARIA of its own. Give the dialog an accessible name with aria-labelledby or aria-label, label icon-only close buttons, and keep a visible close control in the header for anyone who can't perform the gesture. Any element with data-action-hide-dialog closes the sheet.

Browser support

Modern browsers with custom elements, native <dialog>, Pointer Events, and :has(): Chrome 105+, Edge 105+, Safari 15.4+, Firefox 121+. Pointer Events mean mouse, pen, and touch all take the same path, so every gesture on this page works with a mouse.
